1. Adopts uniform speed function to ensure that the material stays in the oven at any position for the same time and rewinding speed.
2. Oven with 4 sides, 4 sides heating, air circulation more smooth.
3. Equipped with heat insulation layer, so as not to scald the operator, saving electricity, energy saving and environmental protection.
4. The suction tension can be arbitrarily stepless adjustment, convenient to control the material tension, to ensure that the printing material does not stretch deformation.
| Technical Parameters | ||||
| Name | Hot air dryer | |||
| Model | LTB-350 | LTB-460 | LTB-600 | LTB-800 |
| Material quality | Baogang-45#steel plate | |||
| Power | 14kw | 14kw | 22kw | 22kw |
| temperature | Room temperature-140℃ | |||
| Insulation layer thickness | 50mm | 50mm | 50mm | 100mm |
| Temperature controller | 2pcs | 2pcs | 4pcs | 4pcs |
| Weight | 400kg | 500kg | 600kg | 700kg |
| Machine Size | L1970*W780*H1810mm | L1970*W900*H1810mm | L2830*W1060*H2150mm | L3000*W1260*H2260mm |
| Optional functions 1) Uniform speed device 2) Radiator fan 3) Automatic double-side dust elimination 4) Correction device 5) Anti-pull device |
||||
? We have rich experience, good technology, service awareness ahead of the professional team, can be timely and effective to solve the problem for you.
? Installation and debug machine for you without any charge. Also, giving technical training for your employees.
? All of our machines can have one year guarantee and lifelong maintenance.
? We can also provide you with printing materials, printing ink and solvents and other raw materials.
